QU50083 Sealing Plug for Input Shafts is used with X10000 Mainshaft Pilot Bearing to prevent oil from leaking through the inside of the Input Shaft on many New Process chain drive transfer cases. Country of origin not known.

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man Tech Notes:

Installation
Matching Parts for Dodge 1994-2002 NP241DHD Transf
Matching Parts for Dodge 1994-2002 NP241DLD Transfg>
Future Use
e=”note1″>Tech Note 1: Interchangeable Bearing Options
Some transfer cases will have this cup and X10000 bearing and some will have QU50114 one piece bearing and cup. The one piece design of QU50114 simplifies installation but it is more expensive than the combined cost of QU50083 and X10000. Both types were used in original equipment applications and are fully and functionally interchangeable.
Future Use

Tech Note 2:Installation
First, clean the inside of the input shaft bearing bore. Next, to minimize the chance of any oil seepage, apply a light film of S64000 Sleeve Retaining Compound to the bearing bore and outside diameter of the cup. Install QU50083 Cup Type Soft Plug to a depth of about 9/16″ below the the lead-in chamfer to the bearing bore. Wipe off any excess Sleeve Retainer from the inside of the bore. InstallX10000 Bearing to flush with, or just below the lead-in chamfer of the input shaft. When properly installed, the bearing will contact QU50083 cup and push it in slightly deeper than it was originally set.

Tech Note 3:Matching Parts for Dodge 1994-2002 NP241DHD Transfer Cases
Exploded View XV4000 1994-1996.5 Dodge Ram NP241DHD Transfer Case
Exploded View XV4001 1996.5-1997 Dodge Ram NP241DHD Transfer Case
Exploded View XV4003 1998-2002 Dodge Ram NP241DHD Transfer Case
QU11039Planetary Lock Plate
QU50873Input Ball Bearing,15/16″ Thick
QU10814 Snap Ring, Input to Planetary
QU10857Input Seal
QU10572Input Shaft to Planet Thrust Washer (uses 2)
QU50494Planetary Assembly, most 1994-1996 NP241DHD and all 1997-2002
QU50150Range Sliding Sleeve
QU10893 Input Shaft Snap Ring
Mopar 68218057AB ATF+4 Transfer Case Fluid, Requires 3-1/4 Quarts to Fill

Tech Note 4:Matching Parts for Dodge 1994-2002 NP241DLD Transfer Cases
Exploded View XV4002 1994-1997 Dodge Ram NP241DLD Transfer Case
Exploded View XV4004 1998-2002 Dodge Ram NP241DLD Transfer Case
QU11039 Planetary Lock Plate
QU50873Input Ball Bearing,15/16″ Thick
QU10814 Snap Ring, Input to Planetary
QU10857Input Seal
QU10572Input Shaft to Planet Thrust Washer (uses 2)
QU50153Planetary Assembly, most 1994-1996 NP241DLD and all 1997-2002
QU50152Range Sliding Sleeve
QU10893 Input Shaft Snap Ring
Mopar 68218057AB ATF+4 Transfer Case Fluid, Requires 2.31 Quarts to Fill

Tech Note 5:Future Use
Future Use

Tech Note 6: Future Use
Future Use

Applications:
(Incomplete, more will be added as time permits)

Dodge:
All Dodge Ram 2500 and Ram 3500 4×4 trucks: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002
